Générateurs de BrouillardNOVUS Enregistreur IP Novus 32 flux dont 16 POE 5 MégaPixels Série 6000
ER6432-IPPOE/F
Caractéristiques Principales
- 16 x Ethernet PoE - RJ-45 interface, 10/100 Mbit/s
- Video and audio channels: 32
- Supported protocols: ONVIF, RTSP
- Recording speed up to 960 fps at 3840 x 2160
- Supports resolution up to 3840 x 2160
- Recorded stream size: 256 Mb/s in total from all cameras
- Internal HDDs mount: 4
- Monitor outputs: 2 (HDMI (4K UltraHD), VGA)
- RACK mount
- Face recognition
Garantie 3 ans
- Stock & Tarif
- Fiche Technique
- Téléchargements
- Produits Associés
| STOCK FABRICANT |
| ER6432-IPPOE/F | |
|---|---|
| Caméras IP | Jusquà 32 canaux résolution 3840 x 2160 (video + audio) |
| Compression | H.264, H.264+, H.265, H.265 Smart |
| Dualstreaming Support | Oui |
| Fisheye Support | yes, 3000/6000 IP series cameras |
| Recording Speed | 960 fps (32 x 30 fps for 3840 x 2160) |
| Stream Size | 256 Mb/s in total from all cameras |
| Recording Mode | time-lapse, triggered by: manual, alarm input, motion detection |
| Prealarm/Postalarm | up to 5 s/up to 600 s |
| Playback Speed | 480 fps (16 x 30 fps) |
| Recorded Data Search | by date/time, events, motion in a defined area, related to face recognition |
| Backup Methods | USB port (HDD or Flash memory), network |
| Backup File Format | AVI, RPAS (player included) |
| Capacité de stockage | jusqu'à 4 x HDD 3.5” 14 TB SATA |
| Total Internal Capacity | 56 TB |
| Internal Alarm Input/Output | 16/4 relay type |
| Camera Alarm Input/Output | supports camera’s alarm input/output |
| Motion Detection | supports camera’s motion detection |
| System Reaction to Alarm Events | buzzer, e-mail, alarm output activation, recording activation, PTZ |
| Analyse d'images | Exception, Scene Change, Video Blurred, Video Color Cast, Tripwire, Zone entrance, Abandoned Object, Object Disappearance, Face Recognition, Perimeter Intrusion Detection by pedestrian or vehicle, Line Cross Detection by pedestrian or vehicle |
| Network Interface | 1 x Ethernet - RJ-45 interface, 10/100/1000 Mbit/s - 16 x Ethernet PoE - RJ-45 interface, 10/100 Mbit/s |
| Network Protocols Support | HTTP, TCP/IP, IPv4, HTTPS, FTP, DHCP, DNS, DDNS, NTP, RTSP, UPnP, SNMP, SMTP |
| ONVIF Protocol Support | Profile S (ONVIF 2.2 or higher) |
| PC/MAC Software | NMS, Internet Explorer, NVR-6000 Viewer, N Control 6000/N Control 6000 |
| Mobile applications | SuperLive Plus (iPhone, Android) |
| Number of Simultaneous Connections | up to 10 clients, up to 36 main streams or 128 substreams or 16 playback streams in total |
| Bandwidth | 256 Mb/s in total to all client workstations |
| PTZ Functions | pan/tilt/zoom, preset commands |
| AUXILIARY INTERFACES | 1 x USB 2.0, 1 x USB 3.0 |
| Operating System | Linux |
| Operation Mode | triplex |
| OSD | languages: Polish, English, others |
| Control | PC mouse and IR remote controller (in-set included), network |
| System Diagnostic | automatic control of: HDDs, network, camera connection loss |
| Security | password protection, IP filtering, MAC filtering |
| Dimensions (mm) | 440 (W) x 70 (H) x 390 (D) |
| Weight | 4.4 kg (without HDD) |
| Power Supply | 100 ~ 240 VAC |
| Power Consumption | 60 W (with 4 HDDs) + 246 W PoE |
| Operating Temperature | -10°C ~ 50°C |
| RACK Mount 19" | 2U |
