Entres Vidéo | 16 x BNC |
---|
Sorties moniteur | 1 x HDMI (4K UltraHD), 1 x VGA (FullHD) |
---|
IP Streams | DVR mode: 16 x BNC + 0 x IP |
---|
Mode hybrid | 16 x BNC + 8 x IP |
---|
Mode IP | 0 x BNC + 24 x IP |
---|
Résolution | max. 2592 x 1944 |
---|
Entrées/sorties Audio | 16 x RCA (Line-in)/1 x HDMI, 1 x RCA |
---|
Format de Compression | H.264, H.265 |
---|
Enregistrement | 480 fps (1280 x 720 - HD), 240 fps (1920 x 1080 - FullHD), 288 fps (1280 x 1440 - 4Mpx Lite), 240 fps (1280 x 1944 - 5Mpx Lite), 128 fps (2560 x 1440 - 4Mpx) |
---|
Enregistrement IP | Mode hybrid 240fps |
---|
Mode IP | 720fps |
---|
Mode IP | 96 Mb/s in total from all IP cameras |
---|
Mode d'enregistrement | continuous, triggered by: REC/PANIC button, alarm input, motion detection, PIR alarm |
---|
Relecture | 480 fps |
---|
Relecture IP | 480 fps |
---|
Recherche de données enregistrées | par date/heure, événements, événements d’analyse d’image, mouvement dans une zone définie, balises |
---|
format de Sauvegarde | JPG, BMP, PNG, MP4, AVI |
---|
Capacité de stockage | 2 x HDD 3.5” SATA ( 28 To au total ) ( non fourni ) |
---|
Entrées/sorties Alarme | 16/1 relay type |
---|
Motion Détection | 36 x 44 grid, individual settings of sensitivity, PIR cameras support |
---|
System Reaction to Alarm Events | buzzer, e-mail, alarm output activation, screen message, recording activation, PTZ, Full Screen, FTP picture upload, FTP vidéo upload, picture to Cloud, vidéo to Cloud |
---|
Fonctions supportées | Exception, Line cross, Zone entrance, Abandoned object, Object disappearance, Face detection, Pedestrian detestion, Cross counting, Sound detection |
---|
Interface réseau | 1 x Ethernet - RJ-45 interface, 10/100 Mbit/s |
---|
Protocoles réseau | HTTP, TCP/IP, IPv4, HTTPS, FTP, DHCP, DNS, DDNS, NTP, RTSP, UPnP, SNMP, SMTP, P2P |
---|
Logiciel PC/MAC | NMS, Internet Explorer, NHDR-5000 Viewer/NHDR-5000 Viewer |
---|
Application Mobile | RxCamView (iPhone, Android) |
---|
Max. Number of Connections with DVR | 20 (live monitoring: 20, playback: 1, configuration: 20) |
---|
Bande passante | 96 Mb/s au total |
---|
Port PTZ | 1 x RS-485 |
---|
Protocole PTZ | Pelco-D, Pelco-P |
---|
Fonctions PTZ | pan/tilt/zoom, preset commands, patterns |
---|
Nombre de canaux POS | 4 |
---|
POS Interface | Ethernet, RS485 |
---|
Ports USB | 1 x USB 3.0, 1 x USB 2.0 |
---|
Système d'exploitation | Linux |
---|
Dimensions (mm) | 378 (W) x 50 (H) x 340 (D) |
---|
Poids | 2.5 kg (sans HDDs) |
---|
Alimentation | 2 VDC (100 ~ 240 VAC/12 VDC PSU in-set included) |
---|
Consommation électrique | 30 W (with 2 HDDs) |
---|
Température de travaille | -10°C ~ 55°C |
